Busbars 150/250/600A
Busbars are used for high current distribution and at the same time they provide connections for batteries and/or DC equipment.
We offer a number of busbars with different current ratings, and a different number of connection terminals. Each busbar is fitted out with a removable protection cover.
Available models:
150A / 70V - 4 high current connections 150A / 70V - 6 high current connections
150A / 70A - 2P with 10 screws +cover
150A / 70A - 2P with 20 screws +cover
250A / 70V - 4 high current connections
250A / 70V - 6 high current connections
250A / 70A - 2P with 6 screws +cover
250A / 70A - 2P with 12 screws +cover
600A / 70V - 4 high current connections and 8 low current connections
600A / 70V - 8 high current connections and 8 low current connections
For more technical information and for the busbar dimensions see the datasheet.
Busbars are used for high current distribution and at the same time they provide connections for batteries and/or DC equipment.
We offer a number of busbars with different current ratings, and a different number of connection terminals. Each busbar is fitted out with a removable protection cover.
Available models:
150A / 70V - 4 high current connections 150A / 70V - 6 high current connections
150A / 70A - 2P with 10 screws +cover
150A / 70A - 2P with 20 screws +cover
250A / 70V - 4 high current connections
250A / 70V - 6 high current connections
250A / 70A - 2P with 6 screws +cover
250A / 70A - 2P with 12 screws +cover
600A / 70V - 4 high current connections and 8 low current connections
600A / 70V - 8 high current connections and 8 low current connections
For more technical information and for the busbar dimensions see the datasheet.
Busbars are used for high current distribution and at the same time they provide connections for batteries and/or DC equipment.
We offer a number of busbars with different current ratings, and a different number of connection terminals. Each busbar is fitted out with a removable protection cover.
Available models:
150A / 70V - 4 high current connections 150A / 70V - 6 high current connections
150A / 70A - 2P with 10 screws +cover
150A / 70A - 2P with 20 screws +cover
250A / 70V - 4 high current connections
250A / 70V - 6 high current connections
250A / 70A - 2P with 6 screws +cover
250A / 70A - 2P with 12 screws +cover
600A / 70V - 4 high current connections and 8 low current connections
600A / 70V - 8 high current connections and 8 low current connections
For more technical information and for the busbar dimensions see the datasheet.
-
-Busbars 2P
150A + Cover - 10 screws - Height: 45mm / Width: 152.4mm / Length: 32mm - 0.3 kg
150A + Cover - 20 screws - Height: 45mm / Width: 232mm / Length: 32mm - 1 kg
250A + Cover - 6 screws - Height: 65mm / Width: 216mm / Length: 86mm - 0.25 kg
250A + Cover - 12 screws - Height: 48mm / Width: 237mm / Length: 70mm - 0.35 kg
-Busbars 4P
150A + Cover - Height: 48mm / Width: 237mm / Length: 70mm - 0.24 kg
250A + Cover - Height: 48mm / Width: 237mm / Length: 70mm - 0.24 kg
600A + Cover - Height: 65mm / Width: 216mm / Length: 86mm - 0.75 kg
-Busbars 6P
150A + Cover - Height: 48mm / Width: 237mm / Length: 70mm - 0.43 kg
250A + Cover - Height: 48mm / Width: 237mm / Length: 70mm - 0.43 kg
-Busbars 8P
600A + Cover - Height: 65mm / Width: 327mm / Length: 86mm - 1.13 kg
-
-
-
